12.10.2 ODU Model Dependent Parameters
Parameter Name
AS
YBDE018-H11
AT
YBDE024-H11
AU
YBDE030-H11
AB
YBD036-H11
AE
YAD036-H13
AF
YAD042-H13
AG
YAD060-H13
AO
YBD042-H11
AP
YBD060-H11
Range
Res.
Range
MinFreqC
23 24 20 20 20 20 20 20 20 0-127 1 Hz
MaxFreqC
79 89 70 90 57 65 70 65 65 0-127 1 Hz
MinFreqH
23 24 20 20 20 20 20 20 20 0-127 1 Hz
MaxFreqH
80 89 75 95 61 70 75 65 65 0-127 1 Hz
DeicerFreq
65 80 80 90 65 70 75 65 70 0-127 1 Hz
Step1Freq
40 40 40 40 40 40 40 40 40 0-127 1 Hz
Step2Freq
65 65 55 60 50 55 55 60 60 0-127 1 Hz
Step3Freq
75 75 65 70 60 65 65 70 70 0-127 1 Hz
Step4Freq
95 95 85 80 80 80 80 80 80 0-127 1 Hz
Step1Time
3 3 3 3 3 3 3 3 3 0-7 1 Min
Step2Time
3 3 3 5 3 3 3 3 3 0-7 1 Min
Step3Time
1 1 1 1 1 1 1 1 1 0-7 1 Min
Step4Time
1 1 1 1 1 1 1 1 1 0-7 1 Min
NightRPS
NA NA NA 70 45 50 55 50 55 0-110 1 RPS
OFMinRPMC
27 27 20 20 15 15 15 15 15 0-130 1 *10RPM
OFMinRPMH
27 27 30 20 20 20 20 20 20 0-130 1 *10RPM
OFMaxRPMC
85 85 85 95 80 85 85 85 85 0-130 1 *10RPM
OFMaxRPMH
NA NA NA 95 80 85 85 85 85 0-130 1 *10RPM
NightRPM
85 75 60 80 50 60 60 60 60 0-130 1 *10RPM
OFNNoiseMaxRPMC
NA NA 78 90 75 75 75 75 75 0-130 1 *10RPM
OFNNoiseMaxRPMH
NA NA NA 95 75 75 75 75 75 0-130 1 *10RPM
OCT_OFAN_Noise_Max
8 8 8 8 8 8 8 8 8 0-15 1 °C
OMT_OFAN_Noise_Max
38 38 35 38 35 35 35 35 35 27-42 1 °C
EEVMinOperOpenC
70 70 70 70 70 70 70 70 70 0 – 1023 1 step
EEVMaxOperOpenC
480 480 480 480 480 480 480 480 480 0 – 1023 1 step
EEVMinOperOpenH
70 70 80 80 70 70 70 80 80 0 – 1023 1 step
EEVMaxOperOpenH
480 480 480 480 480 480 480 480 480 0 – 1023 1 step
CTTOH0
78 78 78 80 80 80 80 80 80 0-120 1 °C
CTTOH1
85 85 85 87 87 87 87 87 87 0-120 1 °C
CTTOH2
90 90 90 90 90 90 90 90 90 0-120 1 °C
CTTOH3
95 95 95 92 92 92 92 92 92 0-120 1 °C
CTTOH4
100 100 100 95 95 95 95 95 95 0-120 1 °C
CTTOH5
105 105 105 96 96 96 96 96 96 0-120 1 °C
CCROC0
8.5 8.5 12 17.0 10.0 10.0 10.0 22.0 22.0 5-40 0.1 A
CCROC1
9.5 9.5 12.6 17.6 11.0 11.0 11.0 23.0 23.0 5-40 0.1 A
CCROC2
10.5 10.5 13.5 18.2 12.0 12.0 12.0 24.0 24.0 5-40 0.1 A
CCROC3
11.5 11.5 15.5 19.0 13.0 13.0 13.0 25.0 25.0 5-40 0.1 A
DCCOC0/ OVRPWR0
2350 2350 2950 12.0 12.0 12.0 12.0 22.0 22.0 5-40 0.1 A
DCCOC1/ OVRPWR1
2500 2500 3050 12.8 13.0 13.0 13.0 23.0 23.0 5-40 0.1 A
DCCOC2/ OVRPWR2
2650 2650 3200 13.2 14.0 14.0 14.0 24.0 24.0 5-40 0.1 A
DCCOC3/ OVRPWR3
2800 2800 3400 13.6 15.0 15.0 15.0 25.0 25.0 5-40 0.1 A
