INTRODUCTION
SM DLSDCI 3-A.1 GB
1. INTRODUCTION
1.1 General
The new DLS DC INVERTER split unit range comprises the following RC (heat pump)
models:
• DLS 18
• DLS 24
• DLS 30
• DLS 36
• DLS 43
Remote control compatibility
The units are compatible with remote controls RC3, RC4, RC7, RC8
Inverter description
Unlike standard units (x RPM) that are selected according to their nominal capacity to
overcome the maximum required load, DC Inverter units can be selected to a smaller
nominal capacity range unit.
It made possible due to the ability of inverters to reach a much higher capacity level
(indicated as Maximum Capacity) which is around 115-130% of the nominal capacity.
1.2 Main Features
High Technology
• Sine wave DC Compressor drive.
• DC-BL-SL (DC Brush-Less Sensor less) Inverter Compressor.
• DC-BL Inverter Outdoor and Indoor Fan.
• Fuzzy Logic Adaptive Control.
System Features
• ECO Design ready
• Variable cooling and heating capacity from 30% to 115% (of rated capacity).
• High COP “A-B” class energy rating (Most units).
• Low noise levels.
• Pre-charged system up to 30m.
• Tubing up to 70m length / 30m height difference (most units).
• Networking connectivity.
• Dry contact inputs:
♦ Forced Standby.
♦ Night mode (for silent operation).
♦ Power Shedding (to control maximum power consumption).
• Dry contact output:
♦ Alarm
♦ Base Heater
♦
Crank Case Heater
• HMI Display consists of 7-segments shows system diagnostics and setup.
