Airwell DLSE Series User Manual

2-7
PRODUCT DATA SHEET
SM DLSDCI 3-A.1 GB
2.7 DLS 43 DCI 1 PH
Model Indoor Unit
DLS 43 DCI
Model Outdoor Unit
YBD 042 H11
Installation Method
DUCTED
Characteristics Units Cooling Heating
Capacity - Nominal (Minimum ~ Maximum)
(1)
Btu/hr 42,650 (15,350-49,470) 47,770 (15,350-54,590)
kW 12.5 (4.5-14.5) 14.0 (4.5-16.0)
Power Input - Nominal (Minimum ~ Maximum)
( (1)
W 3,730 (1,400-4,850) 4,100 (1,100-5,050)
EER (Cooling) or COP(Heating)
(1)
W/W 3.35 3.41
Energy Efciency Class - A B
Power Supply V/Ph/Hz 230 / 1 / 50
Rated Current (Nominal) A 17.4 18.4
Starting Current A <10
Circuit Breaker Rating A 32
INDOOR
Fan Type & Quantity CENTRIFUGAL
Fan Speed H/M/L RPM 870 650 560
Airow
(2)
H/M/L m
3
/hr 2025 1450 1250
External Static Pressure Nom-Max Pa 50-100
Sound Power Level
(3)
H/M/L dB (A) 71 67 62
Sound Pressure Level
(4)
H/M/L dB (A) 52 49 47
Moisture Removal (Nominal) L/hr 3.3
Condensate Drain Tube I.D. mm 16
Dimensions W/H/D mm 854 300 816
Weight kg 33
Package Dimensions W/H/D mm 1010 342 917
Packaged Weight kg 38
Units per Pallet Units 6
Stacking Height Units 6
OUTDOOR
Refrigerant Control Electronic Expansion Valve
Compressor Type, Model Scroll, ANB42
Motor type DCBL Inverter
Fan Type & Quantity Axial 2x 493Фmm
Fan Speed RPM 850-150 (continuous)
Airow Max m
3
/hr 5,700
Sound Power Level Nom dB (A) 68 70
Sound Pressure Level
Nom dB (A) 56 58
Dimensions W/H/D mm 900 1255 340
Weight kg 110
Package Dimensions W/H/D mm 985 1395 435
Packaged Weight kg 120
Units per Pallet Units 1
Stacking Height Units 1
Refrigerant Type R410A
Refrigerant Chargeless Distance kg/m 3.3 / 30
Additional Charge Per 1 Meter g/m 40
Connections
Between Units
Liquid Line In (mm) 3/8” (9.53)
Suction Line In (mm) 3/4” (19.0)
Max. Tubing Length m 70
Max. Height Difference m 30
Operation Control Type LCD Remote Control
Heating Elements kW BH 70W - optional
Others
(1)
Rating conditions in accordance with EN14825 and EN14511 (for ducted units).
(2)
Airow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1.0 meter distance from unit.
