Airwell DLSE Series User Manual

5-2
PERFORMANCE DATA & PRESSURE CURVES
SM DLSDCI 3-A.1 GB
5.1.2 Heating Capacity
ID COIL ENTERING AIR DB TEMPERATURE [°C]
OD COIL
ENTERING AIR
DB/WB
TEMPERATURE
[°C]
DATA 15 20 25
-15/-16
TC 3.56 3.32 3.07
PI 0.88 0.97 1.05
-10/-12
TC 3.97 3.72 3.47
PI 1.06 1.15 1.23
-7/-8
TC 4.27 4.02 3.77
PI 1.19 1.28 1.37
-1/-2
TC 4.42 4.17 3.92
PI 1.26 1.35 1.44
2/1
TC 4.52 4.27 4.02
PI 1.30 1.39 1.48
7/6
TC 5.85
5.60
5.35
PI 1.37
1.46
1.55
10/9
TC 6.17 5.92 5.67
PI 1.45 1.54 1.63
15/12
TC 6.49 6.25 6.00
PI 1.53 1.62 1.71
15-24
TC 85 - 105 % of nominal
(Protection Range)
PI 80 - 120 % of nominal
LEGEND
TC - Total Cooling Capacity, KW
SC - Sensible Capacity, KW
PI - Power Input, KW
WB - Wet Bulb Temp. (⁰C)
DB - Dry Bulb Temp. (⁰C)
ID - Indoor
OD - Outdoor
