Airwell DLSE Series User Manual

12-3
CONTROL SYSTEM
SM DLSDCI 3-A.1 GB
12.2.2 Controller overview
12.2.2.1 Main Controller Indoor Unit (DLS 36/43)
DIP-SWITCHES
RCW Connection
Clock
IR Jumper
Connection to Dis
p
la
y
Cable
Pump
Horizontal LouversIndoor Fan
Fuse 3.15A
Display PCB
Room Sensor (RAT)
Indoor Coil Sensor (ICT)
M2L (PC Tool)
Level
Swing Motor
Power Supply
Comm. To ODU
12.2.2.2 Controller Outdoor Unit (DLS 36/43)
M2L (PC
Power Supply
+ Ground
EEV
IDU-ODU Comm.
Inrush
Driver Comm.
Fuse 3.15A
OFAN_UP
OFAN_DN
RV
OCT
OMT
OAT
CTT
HIGH PRESSURE
A
LARM
Power Shedding
STAND BY
LOW PRESSURE
NIGHT
BASE HEATER
CRANK CASE HEATER
FLASH PORT
DISPLAY HMI
(7-segments)
DIP-SWITCHES
