Airwell DLSE Series User Manual

2-2
PRODUCT DATA SHEET
SM DLSDCI 3-A.1 GB
2.2 DLS 24 DCI
Model Indoor Unit
DLS 24 DCI R410A AW
Model Outdoor Unit
AWAU-YBDE024-H11
Installation Method of Pipe Flared
Characteristics Units Cooling
Heating
Average Warmer
Capacity
(1)
kW 6.8 (1.7÷7.4) 7.6 (1.8÷8.5)
Pdesign kW 6.8 7.5 7.5
SEER / SCOP
(1)
W/W 4.8 3.5 4.0
Energy efciency class B A A+
Annual energy consumption kWh 1,217 4,433 2,347
Tbiv
o
C N/A -3 6
Tol
o
C N/A -15 -10
Power supply V/Ph/Hz 220-240V/Single/50Hz
Circuit breaker rating A 20
INDOOR
Fan type & quantity Centrifugal x 1
Fan speeds H/M/L RPM 800/670/550
Air ow
(2)
H/M/L m3/hr 1310/1115/870
External static pressure Min-Max Pa 25-60
Sound power level
(3)
H/M/L dB(A) 65/60/55
Sound pressure level
(4)
H/M/L dB(A) 47/43/38
Moisture removal l/hr 1.53
Condensate drain tube I.D mm 19
Dimensions WxHxD mm 790x256x749
Weight kg 31
Package dimensions WxHxD mm 960x300x855
Packaged weight kg 33.5
Units per pallet units 6
Stacking height units 6
OUTDOOR
Refrigerant control EEV
Compressor type, model Twin Rotary DC Inverter
Fan type & quantity Axial x 1
Fan speeds RPM 250 - 820 (continuous)
Air ow Max. m3/hr 2,750
Sound power level Nom. dB(A) 67
Sound pressure level Nom. dB(A) 55
Dimensions WxHxD mm 900x700x340
Weight kg 61.0
Package dimensions WxHxD mm 985x730x435
Packaged weight kg 63.5
Units per pallet Units 6
Stacking height units 2 levels
Refrigerant type R410A
Refrigerant charge (standard connecting tubing
length)
kg(7.5m) 2.3
Additional charge per 1 meter gr / 1m 7.5m < 0gr < 15m < 35gr per 1m < 30m
Connections between units
Liquid line In.(mm) 3/8”(9.53)
Suction line In.(mm) 5/8”(15.88)
Max.tubing length m. 30
Max.height difference m. 15
Operation control type Remote control
Heating elements kW
Others
(1) Rating conditions in accordance with EN14825 and EN14511 (for ducted units).
(2) Airow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1.4 meter distance from unit.
