Page 56
CLH LN 402 502 552 602
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 50.6 58.3 65.4 72.5
Rated current A 56.9 67.0 82.0 91.9
Max. current (FLA) A 85.5 98.5 109.5 120.5
Max. start-up current (LRA) A 269 323 371 382
External fuses (A) 100 125 125 160
Max. cable section (1) mm
2
35 50 70 70
CLH LN with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 52.4 60.1 67.2 74.3
Rated current A 61.8 71.9 86.9 96.8
Max. current (FLA) A 90.4 103.4 114.4 125.4
Max. start-up current (LRA) A 274 328 376 387
External fuses (A) 100 125 125 160
Max. cable section (2) mm
2
35 50 70 70
Technical data
CLH LN 182 202 242 302 352
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 19.3 25.9 31.4 36.7 42.8
Rated current A 22.6 31.0 42.3 52.1 52.0
Max. current (FLA) A 32.5 43.7 50.3 61.5 72.3
Max. start-up current (LRA) A 116 150 176 207 256
External fuses (A) 50 63 63 80 100
Max. cable section (1) mm
2
16 25 25 35 35
CLH LN with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 20.1 26.7 32.9 38.2 44.6
Rated current A 24.7 33.1 46.1 55.9 56.9
Max. current (FLA) A 34.6 45.8 54.1 65.3 77.2
Max. start-up current (LRA) A 119 152 180 211 261
External fuses (A) 50 63 63 80 100
Max. cable section (2) mm
2
16 25 25 35 35
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
(2) Data which refer to a single pump.
Unit Electrical data
