Airwell Itelco-Clima CLS 182 STD User Manual

Page 67
English
Technical data
A3 A4
A2 A1
Lato Compressori
V2
V1
C1 C2
A3 A4
A2 A1
Lato Compressori
V3
V2
V1
C1 C2
UNIT WITH 2 PUMPS
Support 4 (A4)Support 3 (A3)Support 2 (A2)Support 1 (A1)Weight (kg)
CLH
182 STD/LN/HPF 702 242 226 109 125
202 STD/LN/HPF 752 255 239 121 137
242 STD/LN/HPF 912 314 297 143 159
302 STD/LN/HPF 962 335 317 146 164
352 STD/LN/HPF 1062 374 353 157 178
402 STD/LN/HPF 1212 419 396 187 210
502 STD/LN/HPF 1212 419 396 187 210
552 STD/LN/HPF 1347 465 440 208 233
602 STD/LN/HPF 1382 477 452 214 239
182 ELN 722 243 227 118 134
202 ELN 772 256 240 130 146
242 ELN 962 315 299 166 182
302 ELN 1012 344 327 162 179
352 ELN 1182 405 384 186 207
402 ELN 1232 425 402 191 214
502 ELN 1232 425 402 191 214
552 ELN 1367 471 446 212 237
602 ELN 1402 483 458 218 243
UNIT WITH 1 PUMP AND 1 TANK
Support 4 (A4)Support 3 (A3)Support 2 (A2)Support 1 (A1)Weight (kg)
CLH
182 STD/LN/HPF 947 327 305 146 169
202 STD/LN/HPF 997 339 317 160 181
242 STD/LN/HPF 1157 398 377 181 202
302 STD/LN/HPF 1362 474 449 207 232
352 STD/LN/HPF 1552 546 516 230 260
402 STD/LN/HPF 1702 588 556 263 295
502 STD/LN/HPF 1702 588 556 263 295
552 STD/LN/HPF 1837 634 600 284 318
602 STD/LN/HPF 1872 647 612 289 324
182 ELN 967 325 304 158 180
202 ELN 1017 337 317 171 192
242 ELN 1362 446 423 235 258
302 ELN 1412 481 457 225 249
352 ELN 1672 574 544 262 292
402 ELN 1722 593 562 268 299
502 ELN 1722 593 562 268 299
552 ELN 1857 640 606 289 323
602 ELN 1892 652 617 294 329
(For the support position, see paragraph 8.5).
Compressor side
Compressor side
