Technical data
177
Cable inlet
35 mm
for transport
only
Lifting point Lifting point
177 36.5
C
36.51037
1110
A
VIEW A
1100
(+35 mm for transport only)
B
VIEW B
2" male
368
470 404
VIEW C
with tank
2"
VIEW C
without tank
501
784 470
2” male
CLH 182-242 STD-LN-HPF / CLH 182-202 ELN
Models Versions Dimensions A (mm) Dimensions B (mm) Dimensions C (mm)
STD 1756 2110 1750
LN/ELN/HPF 1756 2110 1850
STD 1756 2110 1750
LN/ELN/HPF 1756 2110 1850
STD 1756 2110 1750
LN 1756 2110 1850
CLH 182
CLH 202
CLH 242
Note: Do not extract dimensions if not specifyed in the drawings.
