Airwell johnson DCH Series User Manual

SPECIFICATION
Version - 1 10 DCH DCI
3.4 Model: JOSI-DCH018-N11 / JOAU-DCY018-H11
MODEL INDOOR UNIT
JOSI-DCH024-N11
Model Outdoor Unit
AWAU-YCD024-H11
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Heating
Average
Warm
Cold
Capacity
(1)
kW
6.8(2.7-7.8)
7.3(1.6-8.7)
Pdesign
kW
6.8
5.5
6.3
-
SEER /SCOP
(2)
W/W
6.1
4.0
5.1
-
Energy efficiency class
A++
A+
A+++
-
Annual energy consumption
kWh
391
1925
1730
-
Tbiv
o
C
N/A
-7
2
-
Tol
o
C
N/A
-15
Power supply
V/Ph/Hz
220-240V/Single/50Hz
Circuit breaker rating
A
25
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
VL/L/M/H
RPM
900 / 1100 / 1180
Air flow
(3)
VL/L/M/H
m3/hr
640/800/980
External static pressure
Min-Max
Pa
0
Sound power level
(4)
VL/L/M/H
dB(A)
60
Sound pressure level
(5)
VL/L/M/H
dB(A)
32/35/40/44
Moisture removal
l/hr
2.4
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
1040×327×220
Weight
kg
11.9
Package dimensions
WxHxD
mm
1120x310x405
Packaged weight
kg
15.2
Stacking height
units
8
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter
Fan type & quantity
Axial x 1
Fan speeds
H
RPM
810
Air flow
H
m3/hr
2700
Sound power level
(4)
H
dB(A)
66
Sound pressure level
(5)
H
dB(A)
59
Dimensions
WxHxD
mm
845x702x363
Weight
kg
48.4
Package dimensions
WxHxD
mm
965x755x395
Packaged weight
kg
51.6
Stacking height
Units
3
Refrigerant type
R410A
Refrigerant charge (standard connecting tubing length)
kg(5m)
1.85
Additional charge per 1 meter
gr / 1m
15
Connections between units
Liquid line
In.(mm)
3/8"
Suction line
In.(mm)
5/8"
Max.tubing length
m.
50
Max.height difference
m.
25
Operation control type
Remote control
Heating elements
kW
NA
Others
