SPECIFICATION
DCH DCI 9 Version - 1
3.3 Model: JOSI-DCH018-N11 / JOAU-DCY018-H11
MODEL INDOOR UNIT
JOSI-DCH018-N11
Model Outdoor Unit
AWAU-YCD018-H11
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Heating
Average
Warm
Cold
Capacity
(1)
kW
5.0(1.8-6.1)
5.0(1.4~6.7)
Pdesign
kW
5
4.2
4.4
-
SEER /SCOP
(2)
W/W
6.5
4.0
5.1
-
Energy efficiency class
A++
A+
A+++
-
Annual energy consumption
kWh
270
1470
1208
-
Tbiv
o
C
N/A
-7
2
-
Tol
o
C
N/A
-15
Power supply
V/Ph/Hz
220-240V/Single/50Hz
Circuit breaker rating
A
16
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
VL/L/M/H
RPM
700 / 800 / 1100
Air flow
(3)
VL/L/M/H
m3/hr
540/680/840
External static pressure
Min-Max
Pa
0
Sound power level
(4)
VL/L/M/H
dB(A)
57
Sound pressure level
(5)
VL/L/M/H
dB(A)
24/32/36/42
Moisture removal
l/hr
1.7
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
957x302x213
Weight
kg
9.5
Package dimensions
WxHxD
mm
1035x380x295
Packaged weight
kg
12.5
Stacking height
units
8
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter
Fan type & quantity
Axial x 1
Fan speeds
H
RPM
810
Air flow
H
m3/hr
2100
Sound power level
(4)
H
dB(A)
65
Sound pressure level
(5)
H
dB(A)
55
Dimensions
WxHxD
mm
800x554x333
Weight
kg
37.8
Package dimensions
WxHxD
mm
920x615x390
Packaged weight
kg
40.5
Stacking height
Units
4
Refrigerant type
R410A
Refrigerant charge (standard connecting tubing length)
kg(5m)
1.48
Additional charge per 1 meter
gr / 1m
15
Connections between units
Liquid line
In.(mm)
1/4’’
Suction line
In.(mm)
1/2’’
Max.tubing length
m.
30
Max.height difference
m.
20
Operation control type
Remote control
Heating elements
kW
NA
Others
