ELECTRONIC FUNCTION
Version - 1 34 DCH DCI
Reserve
T
Reserve
A
Reserve
S
Reserve
T
When the AC enter into the information enquiry status, it will display the code value in the next 25s, the
details are as follows.
Enquiry
information
Display value
Meaning
Remark
T1,T2,T3,T4,
T2B,TP,TH,
Targeted
Frequency,
Actual
Frequency
-1F,-1E,-1d,-1c,-
1b,-1A
-25,-24,-23,-22,-21,-20
1. All the displaying temperature is
actual value.
2. All the temperature is °C no matter
what kind of remote controller is used.
3. T1,T2,T3,T4,T2B display range:-
25~70,
TP display range:-20~130.
4. Frequency display range: 0~159HZ.
5. If the actual value exceeds the range,
it will display the maximum value or
minimum value.
-19—99
-19—99
A0,A1,…A9
100,101,…109
b0,b1,…b9
110,111,…119
c0,c1,…c9
120,121,…129
d0,d1,…d9
130,131,…139
E0,E1,…E9
140,141,…149
F0,F1,…F9
150,151,…159
Indoor fan
speed
/Outdoor fan
speed
0
OFF
1,2,3,4
Low speed, Medium speed,
High speed, Turbo
For some big capacity motors.
14-FF
Actual fan speed=Display
value turns to decimal
value and then multiply 10.
The unit is RPM.
For some small capacity motors,
display value is from 14-
FF(hexadecimal), the corresponding fan
speed range is from 200-2550RPM.
EXV opening
angle
0-FF
Actual EXV opening
value=Display value turns to
decimal value and then
multiply 2.
Compressor
continuous
running time
0-FF
0-255 minutes
If the actual value exceeds the
range, it will display the maximum
value or minimum value.
Causes of
compressor
stop.
0-99
For the detailed meaning,
please consult with engineer
Decimal display
Reserve
0-FF
Reserve
2~28
Reserve
5~20
Reserve
5~25
