Airwheel H3T User Manual

- 11 -
Rear support leg (optional)
8-1
8-3
8-2
8-4
Rear
support leg
button
vertical tube
Rear
support leg
8-5
rear support
leg
Install the legs:
Press down on the rear leg button and hold it (Figure 8-1), insert the leg into the riser (Figure 8-2), and release the rear leg
button When the rear leg hole is aligned with the vertical tube hole. Then the installation is completed. Disassembling the rear
support leg: press down and hold the button and pull out the foot.
Note: When the rear support leg wheel is mounted downwards, it can be used as an anti-tip wheel (Picture 8-3); when the rear
support leg wheel is mounted upwards (Picture 8-4), it can be used as a rear leg and a rear support. See the  nal use of the it
(Picture 8-5).

Airwheel H3T Specifications

General

Brand	Airwheel
Model	H3T
Category	Wheelchair
Language	English
