Airwheel H3T User Manual

- 6 -
Main Technical Parameters
Size 1076X620X987mm Item weight ~29.6kg
（without battery）
Folding size
842X620X420mm
（
controller size not included
）
Max. load 130kg
Rotation radius 1.2m Frame Aluminum alloy 6061
Standard max. speed 6Km/h Climbing capacity about 9°
Braking performance ≤1.5m Slope capacity about 9°
Charging time about 5H Battery lithium 25.2V 524Wh
Reduction gearbox
worm and gear
reduction ratio 1: 32
Applicable temperature -15
℃
~50
℃
Over-obstacle capacity ≥40mm Trench crossing capacity 100mm
Front wheel 8 inch Rear wheel 12.5 inch, inatable tire
Battery weight 3kg
Motor
Dual-drive brush motor with clutch pull rod. Power: 200W; voltage: 24V;
revolving speed: 4000rpm
Automatic folding
function
a key to automatically contract and extend
Specications

Airwheel H3T Specifications

General

Brand	Airwheel
Model	H3T
Category	Wheelchair
Language	English
