VII. INSTALLING THE CEILING ASSEMBLY
(9600 SERIES)
Make sure that you have properly matched the roof
top heat pump and interior ceiling assembly. The
following step-by-step instructions must be
performed in the following sequence to ensure
proper installation.
A. Remove ceiling assembly from carton, separate
individual items and remove the two grilles and
filters from the ceiling shroud.
B. Fold and break off the 3 tabs around the inner
opening of the duct collar. Fasten the duct collar
to the heat pump basepan with 3 provided
screws (See Figure 9).
C. Raise the ceiling assembly chute and insert the
supply wiring through the cable clamp and into
the wiring box so that 4-6” of supply conductor is
inside the box. Secure the cable clamp over the
supply wire sheath so that no movement is
possible (See Figure 7).
D. Connect the supply power black conductor to the
black pigtail wire, the white conductor to the
white pigtail wire and the supply ground
conductor to the green pigtail wire found in the
wiring box using the 3 provided wire nuts. Using
a U.L. approved electrical tape, secure the wire
nuts to wires in a workmanlike manner (See
Figure 8).
E. Press supply conductors and wire nuts into wiring
box and making sure no wires are pinched,
secure the wire box cover with 2 provided screws
(See Figure 8).
F. Plug the heat pump electrical conduit into the 9-
position receptacle as shown in Figure 7.
G. If the optional heater accessory package is
being installed, remove the cover from the 2-
position receptacle and plug the heater cord into
the receptacle as shown in Figure 7.
H. Raise the ceiling assembly chute to the unit
mounting frame and secure the chute with four
provided screws (See Figure 9).
I. TIE ALL WIRING TO ENSURE NO CONTACT IS
POSSIBLE WITH ANY SHARP EDGES OR
OPTIONAL HEATER IF INSTALLED. KEEP IN
MIND THAT HIGH VELOCITY AIR WILL BE
ENCOUNTERED IN THIS AREA.
J. Pull the fabric duct material through the ceiling
chute discharge opening. Peel the release liner
from the adhesive strip around the opening.
Press the fabric duct material firmly in place
around the opening. Cut off excess fabric on
inside of ceiling chute with a box knife taking care
not to tear the fabric beyond the adhesive strip.
K. Raise the ceiling shroud, ensuring it meshes with
the chute, and secure to the mounting frame with
the four provided screws. (See Figure 9).
L. Install the control knobs over the switch and
thermostat shafts. The thermostat (temperature)
control knob installs nearest the “Coleman-
Mach” logo. If the optional heater accessory is
installed, use the selector switch knob included
in the heater package.
M. Re-install the filter and grilles into the ceiling
assembly shroud.
N. Turn the selector switch to the OFF position.
O. Turn ON the power supply to the roof top heat
pump.
