3.3.2 Airzone Tacto Master Thermostat
• Programming the Master Thermostat
The Master Thermostat Tacto allows programming both the air conditioning of the area
where it is located and the operation of the entire air conditioning system (starting and
stopping the air conditioning system).
- Programming the entire installation:
1) With the thermostat OFF and the mode set at STOP, press the STOP button until
the screen displays P2.
2) Follow the programming steps in the “Automatic Mode Programming” section.
- Programming the area:
1) With the thermostat OFF and the mode set at STOP, press the STOP button until
the screen displays P1 (default option, if you have not set any program which
affects the entire system, you do not need to perform this step).
2) Follow the programming steps in the “Automatic Mode Programming” section.
•
••
• Operating modes
The Airzone Tacto thermostat has two operating modes:
- Manual:
1) This option is selected pressing the hand icon located above the ON/OFF button.
2) It works as the other thermostats of the Airzone range.
3) The air conditioning in the area can be switched on and off (ON/OFF button).
4) The setting point can be modified ( using the adjustment arrows).
Sleep option is available. The Sleep option varies the air conditioning temperature
automatically: in COOL mode, the temperature increases by 0,5ºC every 30
minutes until it reaches 2ºC above the temperature initially set. In HEAT mode, the
temperature decreases by 0,5ºC every 30 minutes until it reaches 2ºC below the
temperature initially set. To activate this option, press the Airzone button and then
the half moon icon located above the adjustment arrows.
- Automatic:
1) This option is selected pressing the letter “A” located above the hand icon.
2) The automatic mode allows you to create “air conditioning scenarios”: connection/
disconnection sequences with a defined set temperature. You can set up to 3 air
conditioning scenarios per day.
3) Separate programs can be created for every day of the week, specific programs for
working days and weekends or programs that affect every day of the week.
4) Sleep option is also available.
5) The time and the day of the week can be seen.
• Automatic mode programming
- Setting the time:
1) With the thermostat OFF, press the Airzone button.
2) Press the numbers which show the time. The day of the week indicator will start to
flash.
3) Use the adjustment arrows to set the day of the week. Press the Airzone button to
validate.
4) Use the adjustment arrows to set the hour. Press the Airzone button to validate.
5) Use the adjustment arrows to set the minutes. Press the Airzone button to validate.
- Program 1
:
