Appendix A: Specifications
Video Formats
1 x 3 Gb SDI (Level A) • (HD) 1920 x 1080p 50, 59.94, 60
1 x 1.5 Gb SDI • (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30
• (HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 30
• (HD) 1920 x 1080i 25, 29.97, 30
• (HD) 1280 x 720p 50, 59.94, 60
1 x 270 Mb SDI • (SD) 625i 25
• (SD) 525i 29.97
Video Input Digital • 1 x 3G-SDI BNC, SMPTE-259/292/424
Video Output
Digital
• 1 x DVI Type D female connector
• Supports DVI v1.0 and HDMI v1.3a, 24/30 bits per pixel, RGB or YUV
• Automatically adapts to popular LCD/DLP/Plasma monitors (and projectors) up to 1920
x 1200 and 1080p
• High quality scaling engine for proper display of 4:3 or 16:9 content-even better quality
than original HDP
• 1 to 1 scaling for appropriate monitor configurations
Audio Input Digital • SDI embedded audio, 24-bit, 8-Channel
Audio Output
Digital
• SDI embedded audio, 24-bit, 8-Channel
• DVI embedded audio, 24-bit, 2-Channel
Audio Output
Analog
• 1 x RCA Stereo analog outputs at -10dBV (nominal)
Size (w x d x h) • 5.8” x 3.1" x 1.0" (147mm x 79mm x 25mm)
Weight •0.7 lb
Power • 5-20VDC regulated, 6.5 watts, power supply required (included with purchase)
