AJAX Button User Manual

The Button is equipped with protection against accidental press and transmits
alarms at a distance of up to 1,300 m from the hub. Please be aware that the
presence of any obstructions that impede the signal (for example, walls or floors)
will reduce this distance.
Button is easy to carry around. You can always keep it on a wrist or a neckless. The
device is resistant to dust and splashes.
When connecting Button via , note that Button does not automatically switch between
the radio networks of the radio signal extender and the hub. You can assign Button to
another hub or ReX manually in the app.
Connecting the button to the Ajax security system
Prior to initiating connection
Only users with administrative rights can add a device to the hub
In order to connect a Button
ReX
1. Follow the hub instructions to install the . Create an account,
add a hub to the app, and create at least one room.
Ajax application
2. Enter the Ajax app.
3. Activate the hub and check your internet connection.
4. Ensure that the hub is not in armed mode and is not being updated by checking
its status in the app.
1. Click on Add Device in the Ajax app.
2. Name the device, scan its QR code (located on the package) or enter it
manually, select a room and a group (if group mode is enabled).

AJAX Button Specifications

General

Type	Wireless panic button
Communication Protocol	Jeweller
Power Supply	CR2032 battery
Battery Life	Up to 5 years
Weight	16 g
Water Resistance	IP54
Number of Buttons	1
Accidental Click Protection	Yes
Transmitter Power	Up to 20 mW
Modulation	GFSK
Operating Humidity	Up to 75%
Ingress Protection	IP54
Communication Range	Up to 1300 meters in open space
Operating Temperature Range	From -10°C to +40°C
Compatibility	Ajax hubs
Alarm Type	Panic
Communication Range with Central Unit	Up to 1300 m in an open space
Operating Frequency	868.0–868.6 MHz or 868.7 – 869.2 MHz, depending on the region
