AJAX Button User Manual

For detection and pairing, the Button must be located within the hub radio
communication zone (on the single protected object).
The connected button will appear in the list of hub devices in the application.
Updating the statuses of the device in the list does not depend on the polling time
value in the hub settings. Data is updated only by pressing the Button.
The Button only works with one hub. When connected to a new hub, the button
Button stops transmitting commands to the old hub. Note that after being added to
the new hub, the Button is not automatically removed from the device list of the old
hub. This must be done manually through the Ajax application.
States
Button statuses can be viewed in the device menu:
Parameter Value
Battery Charge
Battery level of the device. Two states available:
Operating mode Displays the operating mode of the button. Three
modes are available:
3. Click Add and the countdown will begin.
4. Hold the button for 7 seconds. When the Button is added, the LEDs will flash
green once.
1. Ajax app Devices Button
ОК
Battery discharged
How battery charge is displayed in
Ajax apps
Panic
Control

AJAX Button Specifications

General

Type	Wireless panic button
Communication Protocol	Jeweller
Power Supply	CR2032 battery
Battery Life	Up to 5 years
Weight	16 g
Water Resistance	IP54
Number of Buttons	1
Accidental Click Protection	Yes
Transmitter Power	Up to 20 mW
Modulation	GFSK
Operating Humidity	Up to 75%
Ingress Protection	IP54
Communication Range	Up to 1300 meters in open space
Operating Temperature Range	From -10°C to +40°C
Compatibility	Ajax hubs
Alarm Type	Panic
Communication Range with Central Unit	Up to 1300 m in an open space
Operating Frequency	868.0–868.6 MHz or 868.7 – 869.2 MHz, depending on the region
