AJAX KeyPad User Manual

Sound notifications of malfunctions settings are available for all hubs (except the Hub
model) with firmware version OS Malevich 2.15 or higher.
Sound notifications of malfunctions are supported by KeyPad with firmware version
5.57.1.1 or higher.
Event Indication Note
If any device is offline.
Two short sound signals,
Malfunction indicator
Х blinks
twice.
Beep once per minute until all
devices in the system are
online.
Users can delay sound
indication for 12 hours.
If KeyPad is offline.
Two short sound signals,
Malfunction indicator
Х blinks
twice.
Beep once per minute until the
keyboard in the system is
online.
It’s impossible to delay sound
indication.
If battery of any device is low.
Three short sound signals,
Malfunction indicator
Х blinks
three times.
Beep once per minute until the
battery is restored or the
device is removed.
Users can delay sound
indication for 4 hours.
Sound notifications of malfunctions appear when the keypad indication is
finished. If several malfunctions occur in the system, the keypad will notify
about the loss of connection between the device and the hub first.
1. Click Devices , choose hub and open its settings :
Click Service → Sounds and Alerts
2. Enable toggles: If battery of any device is low and If any device is oine.
3. Click Back to save settings.

AJAX KeyPad Specifications

General

Battery Life	Up to 2 years
Operating Humidity	Up to 75%
Communication Protocol	Jeweller
Arm/Disarm	Yes
Panic Button	Yes
Material	Plastic
Backlight	Yes
Type	Wireless
Power Supply	Batteries
Communication Range	Up to 1, 700 m in open space
Operating Temperature	-10°C to +40°C
Encryption	AES encryption
Compatibility	Ajax hubs and range extenders
Tamper Protection	Available
