2 ECS10710D Capacitor Electrolytic 100UF 10V SMD-D 3 C19~21
2 FCN1T0504001 FCN Down Touch ZIF SMD Pitch=0.5mm 40 2 J1,2
Pin
2 IC74AHC541PW IC 74AHC541PW Octal Buffer/Line driver 1 U27
3-state output TSSOP-20
2 ICSN74LV595APWR IC 74LV595A 8-bit SERIAL SHIFT W/LATCHES 18 U4,9~15,22,24,37,42,48,60~64
TRI-STATE TSSOP-16
2 ICYH102M02 IC(AL2-80-0256+Program)TQFP-100 1 U3
3 AL2-80-0256 IC LCMX0256 TQFP-100 1 (U3)
2 LDJ1M1F1BB7R4S3 Liquid-emitting Diode Red/Green/Blue SMD 45 LED1~5,20~27,36~43,52~59,67~74,83~90
0603 angle 120°
2 LDKPT-1608SYCK Liquid-emitting Diode Yellow SMD 0603 8 D124~130,152
angle 120°
2 LDKPTC2012QBC-C BLUE LED KPTC2012QBC-C 0805 8 D307~314
2 LDL-S291SBC-ML Liquid-emitting Diode Orange SMD 0603 294 D1~36,46~69,71~77,79~123,132~150
angle 130° D154,155,157~159,161~168,170~306
D315~319,422~429
2 LDLTST-C190KGKT Liquid-emitting Diode Green SMD 0603 1 D151
angle 130°
2 LDLTST-C190KRKT LED Red 10 D153,156,323~330
2 PC13A002 TOP Panel PCB 2Layer FR-4 1.6T 416*260MM 1 -
2 RS000008J05 RES 0Ω 5% SMD 0805 15 R1,6,9,16,17,20,47,75,85~87,102,104
R106,107
2 RS000010J03 RES 0Ω 5% SMD 0603 3 R2,3,113
2 RS001208F05 RES 12Ω 1% SMD 0805 1 R115
2 RS001M10F03 RES 1M 1% SMD 0603 6 R10,15,84,89,108,109
2 RS002208F05 RES 22Ω 1% SMD 0805 3 R31,38,101
2 RS002408F05 RES 24Ω 1% SMD 0805 1 R99
2 RS002708F05 RES 27Ω 1% SMD 0805 1 R100
2 RS003608F05 RES 36Ω 1% SMD 0805 30 R13,14,21~30,33~35,52~54,59~62,66~73
2 RS004710F03 RES 47Ω 1% SMD 0603 17 R7,8,11,12,65,133,177,180~186,188
R190,198
2 RS006808F05 RES 68Ω 1% SMD 0805 8 R74,191~197
2 RS010K10F03 RES 10K 1% SMD 0603 20 R48,49,55,56,76~83,91~98
2 RS011010F03 RES 110Ω 1% SMD 0603 90 R18,117,118,120,121,124,125,127,129~132
R135,136,138,139,141,142,144,145,147
R148,151~153,155,157,159,162,163,165
R166,168,169,170,172,173~176,178,179
R205,207,209,212,214,215,217,218,220
R223~225,227~230,251,253,255,257,259
R265~272,274~276,290,292,295,298,302
R303,304,306,307,309~315
2 RS022110F03 RES 221Ω 1% SMD 0603 45 R116,119,122,123,126,128,134,137,140,143
R146,149,150,154,156,158,160,161,164,167
R171,204,206,208,210,211,213,216,219,250
R252,254,256,258,261~263,288,289,291,293
R294,296,297,305
2 RS047K10F03 RES 47K 1% SMD 0603 2 R4,41
2 RS04R708J05 RES 4.7Ω 5% SMD 0805 3 R88,114,199
2 RS06R808F05 RES 6.8Ω 1% SMD 0805 3 R19,37,90
2 SWDC11B2020469 Switch Rotational Encode 20Pulse Total 1 ENC1
Length 25mm
2 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 24 SW28~31,41,51~56,57,92~95,104~110,119
2 VRS10304514 POTENTIOMETER SLIDE 10KB 45MM L:11MM 1 P27
DUAL UNIT
2 VRS10304533 Potentiometer Slide 10K 2B 45mm 15mm 9 P18~26
Dual Unit
