2 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 3 Q2,3,5
MMBT4401LT1 NPN SOT-23)
2 AL2-51-4403 Transistor 2N4403 PNP SOT-23 1 Q11
2 AL2-52-5242 Diode MMBZ5242B 1 D15
2 AL2-54-6306 Mosfet FDC6306P P-CH SSOT-6 1 Q4
2 AL2-61-7223 IC NJU7223DL1-33 3.3V TO-252 1 Q1
2 AL4-08-0402 Con USB 4-Pin Female PC-MNT Horizontal 1 J4
2 AL6-02-0001 Switch Push 2P2T Dual Row Lock 1 SW1
2 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 6 C3,9,11,12,15,17
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 2 C7,31
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 18 C4,5,8,10,13,16,19,22,24~28,30,53,54,135,138
2 CS106K1606X5R CCAP SMD 10UF/16V 10% 1206 X5R 4 C23,130,131,137
2 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2 C1,2
2 CS475K1606X7R CCAP SMD 4.7uF/16V 10% 1206 X7R 1 C6
2 DISDBAT54CSM Zener Diode BAST54C 1 D33
2 FCN1T0504001 FCN Down Touch ZIF SMD Pitch=0.5mm 40 Pin 2 J1,2
2 ICLM2738XMY IC LM2738XMY eMSOP-8 1 U38
2 ICYH102M01 IC(ICSTM32F102R8T6+Program)TQFP-64 1 U2
3 ICSTM32F102R8T6 IC STM32F102R8T6 TQFP64 1 (U2)
2 JK6L0670CBKA6A 6.4φ Phone JACK 7PIN 90° Female 1 J5
2 PC13A001 Main PCB 2Layer FR-4 1.6T 175*80MM 1 -
2 RS000008J05 RES 0Ω 5% SMD 0805 3 R18,24,25
2 RS000010J03 RES 0Ω 5% SMD 0603 3 R1,2,17
2 RS000108J05 RES 1.0 Ω 5% SMD 0805 1 R15
2 RS001K10F03 RES 1K 1% SMD 0603 4 R28,30,31,40
2 RS001M10F03 RES 1M 1% SMD 0603 2 R9,41
2 RS002210F03 RES 22Ω 1% SMD 0603 2 R35,36
2 RS004710F03 RES 47Ω 1% SMD 0603 4 R3,6~8
2 RS007508F05 RES 75Ω 1% SMD 0805 1 R21
2 RS010K10F03 RES 10K 1% SMD 0603 9 R12,16,19,23,26,32,44,243,279
2 RS01K510F03 RES 1.5K 1% SMD 0603 1 R37
2 RS021K10F03 RES 21K 1% SMD 0603 1 R280
2 RS022010F03 RES 220Ω 1% SMD 0603 1 R10
2 RS036K10F03 RES 36K 1% SMD 0603 1 R43
2 RS03K310F03 RES 3.3K 1% SMD 0603 1 R29
2 RS047K10F03 RES 47K 1% SMD 0603 1 R38
2 RS820K10F03 RES 820K 1% SMD 0603 1 R39
2 TCS107M100D Solid Tantalum Electrolytic 5 C21,37~39,182
Capacitors100uF/10V 20% D-SMD
2 UHBRI4D15-220M Inducto 22uH 20% 0.65A 0.692 Ohm Dcr SMD 1 L2
2 XTM08000XA1 Crystal Oscillator 8MHZ 5*3.2mm 1 X1
1 TWPC13A00201 TOP PCB Assembly 1
2 AL0-09-0044 Variable Resistor 17 P1~17
2 AL0-17-0102 RES ARRAY 4X1K 10 R32,36,39,40,43~46,57,58
2 AL0-17-0221 RES ARRAY 4X220 1/10W 0603 4 R50,51,63,64
2 AL0-17-0470 RES Array 4X47 1/10W 0603 2 R187,189
2 AL2-54-0138 Mosfet BSS138 N-CH SOT-23 40 Q1~3,5,6,9~22,27~42,48,49,54~56
2 AL2-54-6306 Mosfet FDC6306P P-CH SSOT-6 8 Q44~47,50~53
2 AL2-65-0114 IC 74AHC1G14 SOP-5 1 U74
2 AL2-73-4051 IC74HC4051 Single 8-Chan Mux 16P Soic 6 U1,2,5~8
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 3 C22,103,104
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 108 C1~3,6~17,23~48,50~102,105~108,111
C133,142,150,154,173~177
2 CS106K1606X5R CCAP SMD 10UF/16V 10% 1206 X5R 12 C4,5,18,49,119~122,166~169
2 DIEN1N4148WSM Diode SMD 119 D37~45,70,78,131,160,169,320~322,331~421
D430~433,442~448
