Akai MPD232 Service Manual

2 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 4 C9,57,177,178
2 CS106K0605X5R CCAP SMD 10uF/6.3V 10% 0805 X5R 11 C3,19,20,22,50,78,80,108,147,150,176
2 CS106K1606X5R CCAP SMD 10UF/16V 10% 1206 X5R 2 C48,73
2 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2 C25,49
2 DIBAW56 Switch Diode BAW56 SOT-23 2 D1,4
2 DIPHLTV-356T-B optical coupler Diode LTV-356T-B 1 SEN2
2 DISDMBRA340T3G
Shottky diode DISDMBRA340T3G SMD 3A 40V
1 D7
2 DIZDSMAJ10ASM Diode 11.5V 400W 23A 1 D21
2 ECS10716D Capacitor Electrolytic 100uF/16V D type SMD 5 C6,71,75,165,181
2 FCN1R1001605 FCN UP Touch smd Pitch 1.0mm 16Pin have 1 J19
latch
2 IC74HC595 Integrated Circuit 8 U15,16,19,29,30,62~64
2 ICAP1501K5L ICAP1501K5L T0263-5L 1 U11
2 ICLM393DR IC OPA LM393DR SOIC-8 1 U8
2 ICNJM2387 IC NJM2387 1 U59
2 ICSN74HC02D IC SN74HC02DR SOIC-14 1 U4
2 ICYH103M12 IC(STM32F103VCT6+Program)-LQFP-100 1 U12
2 ICSTM32F103VCT6 IC STM32F103VCT6 LQFP-100 1 (U12)
2 JKDJ-0702B-020 DC Base 2.0MM 1 J7
2 JKK3J15S 1/8" Headphone Jack 2 J2,3
2 LD-19-22SURSYGC LIQUID-EMITTING DIODE RED/GREEN 16 LED48,50,52,54,56,58,60,62,64,66,68
ASTIGMATISM SMD LED70,72,74,76,78
2 LDKPT-1608CGCK Liquid-emitting Diode Green SMD 0603 1 LED98
angle 120°
2 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 0603 1 LED99
angle 120°
2 LDKPT-1608SYCK Liquid-emitting Diode Yellow SMD 0603 17 LED80~82,84~97
angle 120°
2 PC14A017 Main PCB 2Layer FR-4 260x227MM 1.6T 1 -
2 RS000008J05 RES 0Ω 5% SMD 0805 14 R60,61,63,66,94,101,127,132,133,139,142
R148,247,248
2 RS000108J05 RES 1.0 Ω 5% SMD 0805 1 R99
2 RS001508F05 RES 15Ω 1% SMD 0805 1 R235
2 RS001K08F05 RES 1K 1% SMD 0805 4 R128~130,165
2 RS002210F03 RES 22Ω 1% SMD 0603 2 R72,73
2 RS004708F05 RES 47Ω 1% SMD 0805 35 R1,2,7,74,76,77,105,150~153,156~158,167
R173,176~181,216,274,275,280~288,296
2 RS005608F05 RES 56Ω 1% SMD 0805 24 R10,159,161,163,205,207,254,256,258,260
R262,264,266,268,270,272,289~295,297
2 RS006208F05 RES 62Ω 1% SMD 0805 16 R97,160,162,204,206,208,255,257,259,261
R263,265,267,269,271,273
2 RS010004F06 RES 100Ω 1% SMD 1206 2 R112,113
2 RS010008F05 RES 100Ω 1% SMD 0805 1 R172
2 RS010K08F05 RES 10K 1% SMD 0805 84 R3~5,8,9,11,13,14,18~20,35,62,64,67,70
R71,79~90,95,102,115,119,122,134,138
R140,141,143~145,149,164,171,182~203
R209~215,234,237~240,244,246,500~503
2 RS012008F05 RES 120Ω 1% SMD 0805 1 R114
2 RS012K08F05 RES 12K 1% SMD 0805 1 R146
2 RS01K108F05 RES 1.1K 1% SMD 0805 1 R137
2 RS01K508F05 RES 1.5K 1% SMD 0805 1 R147
2 RS022008F05 RES 220Ω 1% SMD 0805 3 R168~170
2 RS027010F03 RES 270Ω 1% SMD 0603 1 R75
2 RS047008F05 RES 470Ω 1% SMD 0805 1 R236
2 RS047508F05 RES 475Ω 1% SMD 0805 1 R136
2 RS068008F05 RES 680Ω 1% SMD 0805 1 R241

Akai MPD232 Specifications

General

MIDI out	Yes
USB version	2.0
USB connector type	USB Type-B
USB ports quantity	1
Product color	Black
Number of drum pads	16
Number of mixer channels	8 channels
Current	1 A
Input voltage	6 V
Power supply type	USB
AC adapter included	No
Minimum RAM	1 GB
Minimum processor speed	1.25 GHz

Weight and Dimensions

Depth	254 mm
Width	422 mm
Height	48 mm
Weight	1900 g
