Akai MPD232 Service Manual

2 RS080608F05 RES 806Ω 1% SMD 0805 1 R135
2 RS100K08F05 RES 100K 1% SMD 0805 3 R48,69,155
2 RS1K9608F05 RES 1.96K 1% SMD 0805 1 R33
2 RS220K08F05 RES 220K 1% SMD 0805 3 R68,124,125
2 RS2K1508F05 RES 2.15K 1% SMD 0805 1 R166
2 RS2K4308F05 RES 2.43K 1% SMD 0805 1 R12
2 RS4K7508F05 RES 4.75K 1% SMD 0805 1 R243
2 RS820K08F05 RES 820K 1% SMD 0805 1 R131
2 RS8K0608F05 RES 8.06K 1% SMD 0805 1 R154
2 SWDC11B20214A8 Switch Rotatiomal 20 pulse 20mm push-on 1 E1
switch
2 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 38 SW0~6,8~14,16~39
2 UHBLM18AG102SN1 BEAD 1000Ω 100MHZ 1 L7
2 UHCBC3225T100MR INDUCTOR 10UH 0.9A 0.133OHM 20% 1210 2 L1,2
2 UHPID1204-101M Inductor 100UH±20% 1.2A 12*12*5MM 1 L3
2 VRR12302501 Potentiometer Rotary 12.5k 2B*2 25mm 8 R21~28
2 VRS10304533 Potentiometer Slide 10K 2B 45mm 15mm 8 R51~58
Dual Unit
2 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental 1 X1
1 TWPC14A01801 Control PCB Assembly 1 30
2 AL3-02-0080 LED Amber L-169XSYDK 8 LED404~411
2 BALE48201-5A LED Fixed 1.5MM 9 (LED403~LED411)
2 FCN2S1001402 FCN Dual Touch 180° Pitch 1.0mm 14P 2 J402,403
2 JW5206T Jumping Wire 1 JS1
2 LDIFR324HDHK Liquid-Emitting Diode Red Spotlight 1 LED403
φ3mm Round Red Diffused 400mcd DIP
2 PC14A018 Control PCB 1Layer FR-1 137x86MM 1.6T 1 -
2 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 12 SW440~451

Akai MPD232 Specifications

General

MIDI out	Yes
USB version	2.0
USB connector type	USB Type-B
USB ports quantity	1
Product color	Black
Number of drum pads	16
Number of mixer channels	8 channels
Current	1 A
Input voltage	6 V
Power supply type	USB
AC adapter included	No
Minimum RAM	1 GB
Minimum processor speed	1.25 GHz

Weight and Dimensions

Depth	254 mm
Width	422 mm
Height	48 mm
Weight	1900 g
