AKO 16523 - Evaporator Fans

1652H311 Ed.03
15
Description
Values
Min.
Def.
Max.
fAN
F0
Shutdown temperature of fans
ºC/ºF
-50
4.0
50
F1
Probe 2 differential if fans are shut down
ºC/ºF
0.1
2.0
20.0
F2
Shut down fans when the compressor shuts down 0=No 1=Yes
0
0
1
F3
Status of the fans during the defrost 0=Shut down; 1=Running
0
0
1
F4
Delay of start-up after defrost (If F3=0)
It will only actuate if it is higher than d9
Min.
0
2
99
EP
Exit to level 1
Description
Values
Min.
Def.
Max.
DEF
d0
Defrost frequency (Time between 2 starts)
H.
0
6
96
d1
Maximum defrost duration (0=defrost deactivated)
Min.
0
*
255
d2
Type of message during the defrost:
0=Displays the real temperature; 1=Displays the temperature at the start of the
defrost; 2=Displays the dEF message
0
2
2
d3
Maximum duration of the message
(Time added at the end of the defrost process)
Min.
0
5
255
d4
Final defrost temperature (by probe) (If P4 ¹ 1)
ºC/ºF
-50
8.0
C2
d5
Defrost on connecting the unit: 0=NO First defrost according to d0;
1=YES, First defrost according to d6
0
0
1
d6
Delay of the defrost start on connecting the unit
Min.
0
0
255
d7
Type of defrost: 0=Resistors; 1=Air/fans
2=Hot gas; 3=Reversal of cycle
0
*
3
d8
Count of time between defrost periods:
0=Total real time 1 =Sum of compressor connected time
0
0
1
d9
Drip time when completing defrost (Shutdown of compressor and fans)
Min.
0
1
255
EP
Exit to level 1
Level 1 Level 1 Level 2 Level 2
Defrost
Evaporator fans
* According to wizard.
It can only be modified using the configuration wizard (InI).
Description
Values
Min.
Def.
Max.
RE
C21
Probe to be displayed 0=All probes (sequential)
1=Probe 1 (Chamber) 2=Probe 2 (Evaporator) 3=Probe 3 (According to I20)
0
1
3
C22
Stop fans and compressor on opening door 0=No 1=Yes
0
0
1
C23
Start-up delay for fans and compressor with door open
Min.
0
0
999
C27
Probe 3 calibration (Offset)
ºC/ºF
-20.0
0.0
20.0
EP
Exit to level 1
Level 1 Level 2
Regulation and control
