AKO 16523 - Inputs and Outputs

1652H311 Ed.03
17
Description
Values
Min.
Def.
Max.
In0
I00
Connected probes 1=Probe 1 (Cold room)
2=Probe 1 (Cold room) + Probe 2 (Evaporator)
1
2
2
I10
Configuration of digital input 1
0= Deactivated 1=Door contact 2=External alarm
3=Severe external alarm 4=Change of SP 5=Remote defrost
6=Defrost block 7= Low pressure switch
0
*
7
I11
Polarity of the digital input 1
0=Activates on closing contact; 1=Activates on opening contact
0
0
1
I20
Configuration of digital input 2 0= Deactivated
1=Door contac 2=2=External alarm 3=Severe external alarm
4=Change of SP 5=Remote defrost 6=Defrost block
7=Register probe 8=Probe 2° evaporator ** 9=High pressure switch for Hot Gas
0
0
9
I21
Polarity of the digital input 2
0=Activates on closing contact; 1=Activates on opening contact
0
0
1
O00
Configuration of relay AUX1 0=Deactivated 1=Compressor/Resistor sump
2=Light 3=Virtual control
0
*
3
O10
Configuration of relay AUX2 (Not available in AKO-16523/16520)
0=Deactivated 1=Alarm 2=Light 3=Virtual control
4=Door frame resistance 5=Defrost 2° evaporator
0
2
5
EP
Exit to level 1
Level 1 Level 2
Inputs and outputs
Description
Values
Min.
Def.
Max.
KCP
h1
Maximum temperature of HACCP alarm
ºC/ºF
-50
99
99
h2
Maximum permitted time for activation of the HACCP alarm (0=Disabled)
H.
0
0
255
EP
Exit to level 1
Level 1 Level 2
HACCP alarm
Description
Values
Min.
Def.
Max.
TiD
IN{
Option chosen in the configuration wizard
Pd
Pump down active? 0=No 1=Yesi
PU
Programme version
Pr
Programme revision
EP
Exit to level 1
Level 1 Level 2
Information (Reading only)
* According to wizard.
** Option not available in AKO-16523 / 16520
English
†
†
†
It can only be modified using the configuration wizard (InI).
†
