Status Messages – Broadcast (continued)
Message type 0x83 – CAN Outputs
This message is issued periodically (100ms) to allow the 6037xxxx Wireless Interface to display status indications.
Header (29 bits) 2 22 11 00 0
8... 43.....65.....87.....0
110001110111111111111 [ A ]
3 bits, Priority 6 (110)
2 bits, 00
8 bits, 0xEF
8 bits, Target (0xFF - Broadcast)
[A] = 8 bits, Source (AB node address)
Data length – 3 bytes
Data byte 0 1 2
bit 7......07......07......0
10000011 [ A ]
8 bits, Message type 0x83
[A] 16 bits, Flags (bit map)
0x0010 – Deployed status ...........1....
(currently unused) 11111111111.1111
Example – 18EFFF80 [3] 83 00 10
This message indicates the status of the unit at CAN node address ‘0x80’:
Unit is deployed / not stowed
[ Flags = 0x0010 ]
34
