After-Sales / Service
Type CS 4030
Usable saw length 265mm
Saw chain 91P045X
Drive link thickness 1.27mm
Chain sprocket pitch 3/8”
Chain brake Yes (electrical, PCB and
brake rod)
Chain run-on time (DIN EN 60745-2-13 – 19.107.1) Max. 0.15s
Chain run-on time (DIN EN 60745-2-13 – 19.113) Max. 2s
Activation of the chain Twofold
Chain oil tank volume 180ml
Weight with guide rail and saw chain 4.45kg
Weight without guide rail and saw chain 3.9kg
Overload protection No
Sound power level LwA (DIN EN ISO 3744) 101dB(A)
Sound pressure level LpA (DIN EN ISO 3744) 91.5 dB(A), K = ±3dB(A)
Vibration value (DIN EN 28662-1) 3.159m/s
2
– 3.193m/s
2
K
=±1.5m/s
2
Battery B150Li / B200Li
Rated voltage 36V (40V max.)
Rated capacity 4Ah / 5Ah
Charging duration approx. 90min / approx.
120min
Charging unit C130Li
Mains voltage 100V – 240V (AC)
Mains frequency 50/60Hz
Output voltage 42V (DC)
Operating temperature range +5°C – +40°C
21 AFTER-SALES / SERVICE
In the event of questions of warranty, repair or
spare parts, please contact your nearest AL-
KOService Centre. These can be found on the
Internet at:
www.al-ko.com/service-contacts
