Albany 355 - Electrical Installation Details; Terminal Connections and Safety Warnings

16 Nov. 2006
Label What Plug Location
X31 THERMAL SWITCH 3 WIRE BLK. WIRE MOTOR
X33 TOP OPEN PROX. 3 WIRE BLK. WIRE SIDE FRAME
X35 PHOTOCELL RECEIVER 3 WIRE LEFT SIDE FRAME
X36 PHOTOCELL TRANSMITTER 3 WIRE RIGHT SIDE FRAME
X37.1 CSE RECIEVER 4 WIRE RIGHT SIDE FRAME
X38.1 CSE TRANSMITTER 4 WIRE LEFT SIDE FRAME
WARNING
BEFORE APPLYING POWER TO CONTROL PANEL, CHECK LINE VOLTAGE AT
DISCONNECT WITH A VOLTMETER.
FIGURE 11
