6 Nov. 2006
PACKING LIST
Before beginning the installation, thoroughly inspect the crate to ensure all necessary
components are there. The following list applies to a standard Model 355 door
(No optional parts are included unless ordered that way).
• Left Hand and Right Hand Side Columns with attached Covers (1 set)
• Top Roll Assembly (1)
• Drive Unit w/torque arrestor bracket (1)
• Electrical Control Panel (1)
• Safety Photocells (1 set)1
• Bottom Rail Profile (1)
• Counterbalance Springs (2)
• Tensioning Ropes (2)
• Width Gauge
• Assembly Hardware
OPTIONAL PARTS
• Motion Detector
• Floor Loop
• Transmitters
• Auxiliary Pushbuttons Stations
• Pull Cords
SUGGESTED TOOLS REQUIRED
• 5mm allen wrench • Water Level
• 6mm allen wrench • Carpenters Level
• 8mm allen wrench • Hammer
• 18mm open end wrench • Wrench set (SAE)
• Screwdriver • Screwdriver Set
• Tape Measure
• Come-a-along
• Wrench set (METRIC)
• Drill bits
