Alcatel-Lucent 8058s Premium User Manual

Premium DeskPhone
8AL90339ENACed01
24 /107
Manage your call forwarding by pressing the key associated with the forward icon.
• Stationary white icon: No forwarding activated.
• Rotating arrow: Forwarding activated.
1.6.3 Call management screen
Tabs: Incoming call, Call
in progress, Call on hold,
…
Softkeys: actions
available depending on
the call status (when
presentation screen is
not displayed)
Notification (popup) of
incoming call
Each tab corresponds to a call, the status of which is symbolized by its icon (in progress,
call on hold, arrival of new call). When a call is in progress, use the left-right navigator to
look at calls on hold or incoming calls.
All features are accessible while the call is displayed on the screen. Use the Up and Down
arrows to move up or down a page. These functions (transfer, conference, etc.) are directly
related to the status of the call consulted. For example, the transfer function will not be
available between a call in progress or on hold and an incoming call.
Use to switch to the main screen during conversation to access some functions, for
example, searching by name.
Press the key in front of the label to select the corresponding feature.
Calls can also be managed from the Perso page.
While the call is in progress, press the Back/Exit key and display the Perso page. Calls in progress or
waiting calls are displayed on the different line keys. It is then possible to converse with the contact
of your choice by pressing the key associated to the contact.
1.6.4 Function keys and programmable keys
The 8008 DeskPhone uses 3 preprogrammed keys to access some features. In this case,
the icon of the feature is printed on the paper. Use the feature by pressing the
corresponding key. When activated, the LED corresponding to the key remains lit up. Press
the corresponding key to deactivate it.
• 123<>abc Alpha-numerical keypad
Use this key to switch between alphabetic keyboard and numeric keyboard.
• Programmable keys (F1 and F2 keys). A service or a direct call can be associated to these
keys.

Alcatel-Lucent 8058s Premium Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Voice codecs	CNG, G.711alaw, G.711ulaw, G.722, G.729ab, OPUS, VAD
Comfort noise generation (CNG)	Yes
Number of handles included	1 pc(s)
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	5 - 95 %
Volume control	Buttons
Number of programmable keys	4
AC adapter input voltage	100-240 V
Certification	EN 60950-1(+A11 +A1 +A12 +A2), IEC 60950-1 (+Am1 +Am2), ANSI/UL 60950-1, CAN/CSA-C22.2 NO. 60950-1-07 (+Am1 +Am2) EN 300 328 FCC 47 CFR 15 C RSS-247 AS/NZS 4268 EN 55022 B EN 55032 B 47 CFR 15 B B ICES-003 B EN 55024 EN 61000-6-1 EN 61000-6-2 EN 61000-6-3 EN 61000-6-4 IEC 60945 IEC 62236-4 EN 301 489-1 EN 301 489-17 EN 61000-3-2 EN 61000-3-3 TIA / EIA 810-B, TIA 920.130-A-1, AS/CA S004 FCC47 CFR 68, CS-03 V, AS/ACIF S040 2009/125/EC, ROHS 2011/65/EU, WEEE 2012/19/EU
Lines quantity	- lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Headset connectivity	3.5mm
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Security algorithms	EAP-TLS, MD5, TLS
Networking standards	IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af, IEEE 802.3az
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Handset type	Wired handset
Product type	IP Phone
Product color	Gray

Weight and Dimensions

Depth	200 mm
Width	252 mm
Height	204 mm
Weight	1350 g
