To connect the set to the LAN:
1. Turn the set over so that you can see its base.
2. Plug the RJ45 cable into the set's LAN connector.
3. Connect the RJ45 cable to the LAN.
Initializing the sets
This section describes how to:
- Select the initialization mode
- Initialize the 4135 IP Conference Phone set
Selecting the initialization type
The default initialization is dynamic Alcatel-Lucent Enterprise.
To select the initialization type, refer to the table below.
table 4.23: Initialization type selection
If Then the required ini-
tialization mode is
Further information
You use OmniPCX
Office DHCP server
Dynamic or Proprietary
Dynamic
- Refer to Configuring OmniPCX Office
DHCP server
You use another DH-
CP server
Dynamic - Refer to Configuring an external DHCP
server
You do not use a DH-
CP server
Static - Refer to Configuring network parameters
for static initialization
- Obtain from your network administrator:
• An IP address for the 4135 IP Con-
ference Phone set
• The subnetwork mask
• The router address
• The DNS addresses (primary ans
secondary)
• The VLAN ID (if VLAN is used)
• The IP address of the Alcatel-Lucent
OmniPCX Office Communication
Server for configuration files down-
load
Note:
You need to know the set directory number.
Configuring OmniPCX Office DHCP server
As of R9.1, the OmniPCX Office DHCP server is enabled by default during startup wizard
installation. If enabled, 4135 IP Conference Phone sets automatically initialize in dynamic
mode, when plugged to the OmniPCX Office. In other words, 4135 IP Conference Phone
automatically get their IP configuration from the OmniPCX Office DHCP server.
If the OmniPCX Office DHCP server disabled, you can enable it as follows:
- In OMC, go to Hardware and Limits > LAN/IP Configuration > DNS/DHCP.
Chapter
4
&'(
4-52
