1. Turn the set over so that you can see its base.
2. Plug the RJ45 cable into the set's LAN connector.
3. Connect the RJ45 cable to the LAN itself.
Connecting power supply
The set can be supplied from two possible power sources:
- An AC/DC external adapter which is a 42V power supply
A female jack is used to connect the power adapter. The AC/DC external adapter is the
same for IP Touch and e-Reflex sets.
- Power over Ethernet (PoE)
The supply via Ethernet can be implemented using a 802.3af standard-compatible switch.
To supply power via an AC/DC external adapter:
1. Plug the appropriate cable from the adapter into the set's power supply connector.
2. Connect the plug from the adapter to the mains power supply.
Initialization starts.
Initializing the sets
This section describes how to:
- Choose the initialization mode
- Initialize the IP Touch set
Prerequisites
The IP Touch set must be connected to the:
- LAN
- Power supply
Choosing the initialization mode
The default mode is dynamic Alcatel-Lucent Enterprise mode.
To choose the initialization mode, refer to the table below.
table 4.26: Initialization modes
If Then the required initializa-
tion mode is
And
You use OmniPCX Office DH-
CP server
Dynamic or Proprietary Dy-
namic
- Refer to table: Initialization
procedure
You use another DHCP server Dynamic mode Refer to table: Initialization
procedure
Chapter
4
&'(
4-60
