- AOM Alcatel-Lucent 8 series and Alcatel-Lucent 9 series Smart Display Module provides
14 keys with programmable LCD labels
Prerequisites
None.
Rules and restrictions
The following rules apply to the use of Add-On Modules with the Alcatel-Lucent IP Touch
4028 Phone, Alcatel-Lucent IP Touch 4038 Phone and Alcatel-Lucent IP Touch 4068 Phone
sets:
- A maximum of three Add-On Modules of the types AOM10 and AOM40 can be connected
to each set, providing up to 120 additional keys.
- A maximum of three Smart Display Modules can be connected to each set, providing up to
42 additional keys.
- Add-On Modules of types AOM10 and AOM40 can be used on the same set, but a Smart
Display Module cannot be used in conjunction with an AOM10 or AOM40.
- If an AOM10 is used with other Add-On Modules, it must be connected as the last module
on the far right of the set.
Connecting Add-On Modules
To connect an Add-On Module:
1. Remove the tab located on the right side of the IP Touch set.
2. Plug the Add-On Module's RJ45 connector into the set's RJ45 connector.
3. Insert the Add-On Module attachments into the appropriate holes located on the right side
of the IP Touch set.
4. Screw the Add-On Module to the IP Touch set.
Note:
If the IP Touch set is on when you plug in an Add-On Module, you must restart the set after connection.
Connecting headsets
The headset jack is located on the left side of the set.
The 3.5 mm female jack can receive a headset jack.
The hands-free key allows you to switch from handset, headset and hands-free.
Prerequisites
None.
Connecting a headset
To connect a headset, simply plug the headset jack into the associated connector on the side
of the set.
Connecting external station speakers
The external station speaker jack is located on the left side of the IP Touch set.
