7. Click Add. The Installation window is displayed.
8. In the Installation window, check Don't detect my modem. Propose the option in a list
and click on Next.
9. Select the manufacturer.
10. Select Alcatel-Lucent OmniPCX Direct V24 (for Windows XP/2003/2000).
11. Select the Com port used.
12. Click Next.
13. Click Finish.
14. Click Close.
15. Back in OMC, click Comm. The Local V24 box is now enabled and the Com port is
displayed.
16. Click Ok and enter the password. It will take a few seconds for the OMC to connect to the
system.
6.2.3.4 OMC Remote Access By Modem
With remote access, you can use OMC to configure or download an Alcatel-Lucent OmniPCX
Office Communication Server system. This access can be managed using:
- an ISDN modem able to use ISDN PPP (point to point) protocol at 64K (1 B-channel) or
128K (2 B-channels)
- a V34 analog modem in Hayes protocol at 33600 bds
The management of these two modems is integrated into Alcatel-Lucent OmniPCX Office
Communication Server.
Important:
The OMC software must be installed on the remote maintenance PC, if Windows Terminal Server
is not being used.
6.2.3.4.1 Remote Access By ISDN Modem
ISDN Modem Recommended
Alcatel-Lucent OmniPCX Office Communication Server is equipped with a 64K (1
B-channel)/128K (2 B-channels) ISDN modem using PPP protocol for remote access through
the public network. It provides a point-to-point link accessible via standard LINUX procedures
(PPP, etc.).
For a 64K (1 B-channel) connection, the following modems are validated:
- KORTEX NOVAFAX ISDN 128000/33600 with PPP protocol
- FRITZ ¡X CAPI 2.0 or any standard "FRITZ" modem
- Multitech I Way Hopper MTA 128 ST 128 KBPS ISDN (see note below)
For a 128K (2 B-channels) connection, the following modems are validated:
- OLITEC USB ISDN 128K
- Multitech MTA128ST-RC ML-PPP (see note below)
- Eicon Diva 852 ISDN T/A USB - ISDN BRI ST - 128 Kbits/s
Chapter
6
*
6-18
