2. Connect the set, refer to Connecting the set
3. If necessary, configure the user name and password in OMC, refer to Configuring the user
name and password in OMC
Prerequisites
- The Alcatel-Lucent OmniPCX Office Communication Server version must be R810 or
higher and the system must be operational
- For network configuration, any of the following must be implemented:
• In dynamic mode, a DHCP server must be configured
• In static mode, a free IP address must be available for the set
- A port with PoE must be available on a switch. If not available, a PoE injector must be
used
Connecting the set
This section describes how to:
- Connect an 8082 My IC Phone set to the LAN (Local Area Network)
- Connect the external power adapter, if necessary
Note:
The external power adaptor is compatible with 8082 My IC Phone HW2, it is not compatible with version
HW1.
Connecting an 8082 My IC Phone set to the LAN
To connect the set to the LAN:
- If you are using the 8082 Power Over Ethernet Injector Kit:
a. Plug an RJ45 cable between the data in port of the kit and the LAN
b. Plug an RJ45 cable between the data and power out port of the kit and the set LAN
connector
c. Plug the kit to the mains
- If you are not using the 8082 Power Over Ethernet Injector Kit, plug an RJ45 cable
between the set LAN connector and a port of the switch
Connecting power supply
Note:
Only available for 8082 My IC Phone HW2
If you are not using a PoE switch or the 8082 Power Over Ethernet Injector Kit, connect the
AC/DC external adapter:
1. Plug the appropriate cable from the adapter into the set's power supply connector.
2. Connect the plug from the adapter to the mains power supply.
Initializing the sets
The following sections describe how to:
- Select the initialization type
&'(
4-41
