Cleaning and maintenance
25
www.isc-gmbh.info
AFTER SALES SUPPORT
GB
IRE
0044 151 649 1500
0044 1890 946 244
GB IRE
Changing the oil
The compressor is shipped with the synthetic oil SAE 10W40. Completely replace the oil
of the pump system after the first 100 hours of operation. You will need an open-end-
ed spanner or a ring spanner with a width of AF 24.
1. Make sure that the compressor is switched off and the mains plug has been pulled.
2. Loosen the oil drain plug
12
with an open-ended spanner or a ring spanner (see
fig. A and F).
3. Hold a collecting container, e.g. metal trough, under the oil drain plug and, if nec-
essary, tip the compressor slightly so that all the oil drains out of the compressor.
4. Screw the oil drain plug back onto the compressor and tighten it with an
open-ended spanner or a ring spanner.
5. Add new oil as described in the chapter “Adding oil”.
Adding oil
1. Make sure that the compressor is switched off and the mains plug has been pulled.
2. Pull the oil plug
20
out of the oil fill opening
23
(see fig. A and D).
3. Add as much oil so that the housing is covered with oil up to the red dot in the
middle of the view window (see fig. F).
4. Insert the oil plug firmly into the oil fill opening.
Replacing the mains connection line
WARNING!
Risk of electric shock!
If the mains connection line is damaged or is improperly mounted, there is a
risk of electric shock.
− The mains connection line may only be replaced by the manufacturer, its
customer service or a similarly qualified specialist to avoid risks.
− If the mains connection line of this device is damaged, have it replaced by a qual-
ified specialist before using the device again.
