ALDI Workzone WAC 3050/1 User Manual

Product contents⁄device parts
1
Overload switch
22
Support foot bracket
2
Air filter, 2×
23
Oil fill opening
3
Handle
4
Wheel, 2×
5
Drain cock for condensed water
(drain valve)
6
Screw, 2×
7
Support foot, 2×
8
Washer, 8×
9
Nut, 4×
10
Axle screw, 2×
11
Spring washer, 2 ×
12
Oil drain plug
13
Safety valve
14
Quick coupling 2×
15
Operating pressure gauge
16
Pressure regulator
17
Tank pressure gauge
18
Transport handle
19
On/Off switch (with automatic pres-
sure switch)
20
Oil plug
21
Wheel support bracket
GB IRE

ALDI Workzone WAC 3050/1 Specifications

General

Brand	ALDI
Model	Workzone WAC 3050/1
Category	Air Compressor
Language	English
