9. To increase the operating pressure, turn the pressure regulator
16
clockwise. To
reduce the pressure, turn the pressure regulator counterclockwise (see fig. A and H).
You can read the set pressure on the operating pressure gauge
15
.
You can read the pressure of the air contained in the compressed air tank on the
tank pressure gauge
17
. The tank pressure cannot be adjusted.
10. To switch the compressor off, set the On/Off switch to the “0” position (push it down).
11. If you no longer wish to use the compressor, pull the mains plug out of the socket.
12. Vent the compressor via the connected pneumatic tool, e.g. a blow gun.
13. Take the pneumatic tool off of the compressor by slightly pushing the quick cou-
pling
14
back and pulling the pneumatic tool off (see fig. A and H).
14. Let the compressor cool off completely.
15. Clean the compressor as described in the chapter “Cleaning and maintenance”.
Starting the compressor after an overload
The compressor is equipped with an overload switch. If the compressor is overloaded,
the overload switch automatically deactivates it to protect the compressor from over-
heating. If the overload switch has triggered, proceed as follows:
1. Push the On/Off switch
19
down to switch the compressor off (see fig. A and G).
2. Wait until the compressor has cooled off.
3. Push the overload switch
1
.
4. Switch the compressor on as described in the chapter “Using the compressor”.
Cleaning and maintenance
WARNING!
Danger of explosion!
The compressed air tank or the attached tools may be in a pressurised state.
− Before performing any cleaning and maintenance, completely depressurise
the tank.
− Regularly maintain the compressor and have necessary maintenance and
repair work performed without delay.
