Medium-Pressure Stub Pump SER 9668
Alemite Corporation 9 Revision (1-97)
WARNING
Should leakage occur anywhere within the
system, disconnect air to the motor. Personal
injury can occur.
With air pressure at zero:
6. Attach a control valve to the outlet hose of the pump.
• Make sure the nozzle on the control valve is open.
7. Slowly supply air pressure to the pump’s motor.
8. Allow the pump to cycle slowly until the oil is once
again free of air.
9. Set the air pressure to the normal operating pressure.
10. Operate the control valve into a container.
11. Shut off the control valve.
• Visually inspect the pump for external leaks.
• The pump should not cycle more than once or twice
in one hour.
If the pump does not stall, refer to the
Troubleshooting Chart for details.
12. Check the motor for air leakage.
If the motor leaks, refer to the Air Motor Service
Guide for details.
Installation
Additional items that should be incorporated into the
air piping systems are listed in Table 4.
Part Number Description
5604-2
Moisture Separator
7604-B
Regulator and Gauge
Table 4 Air Line Components
