Using the Pulse Companion 20
Wall Mounting
Removing the Pulse Companion from Service
Remove the base by inserting a at-headed screwdriver
into the slot, apply gentle pressure and turn the
screwdriver, the base will then pop away from the top.
The two holes in the base can then be used to attach the
device to a wall or surface.
A wall mounting kit consisting of sticky pads, and two
countersunk screws with wall plugs is included in the box.
The device can be turned off by holding the •
•
• button for 8 seconds, the light will ash red rapidly when shutting
down. Upon shutting down it will send out an “Alarm Off” call to the pager (This will stay on the pager permanently
until the device is turned back on).
IMPORTANT:
The pulse companion can be deactivated or
removed from the pagers memory if required.
Please contact support for assistance if needed.
Figure 10
