Alesis DM Pro Kit - Rack and Mounting Hardware Checklist; Trigger Pad Checklist

Rack and Mounting Hardware Checklist - ( F i g u r e 1)
Trigger Pad Checklist
2 DM Pro Kit Setup Guide
Q t y. P a r t Description
2 Rack Bases
2 Upright Tu b e s
1 Center Tube (w/ 3 memory locks)
1 Right Side Tube (w/ 1 memory
l o c k )
1 Left Side Tube (w/ 2 memory
l o c k s )
4 Rack Tube T- C l a m p s
Q t y. P a rt Description
8 Hardware Clamps
4 Tom A r m s
1 Long Snare A r m
2 Cymbal Booms
1 DM Pro Rack Mounting Tray
w/screws and washers
1 Small Utility Tray (not pictured)
2 Drum Keys (not pictured)
5 Cable Ties (not pictured)
Figure 1: Rack and Mounting Hardware layout
Q t y. P a r t Description
1 Snare Pad
3 Tom Pads
1 Kick Trigger w/ Inverted Beater
1 Hi-hat Pedal
Q t y. P a r t Description
1 Hi-hat Cymbal
1 Crash Cymbal w/ Spring Collar
1 Ride Cymbal
2 Rubber Cymbal Mats
