ALESIS FUSION EDITING AN ANALOG SYNTH PROGRAM
You will note the JUMP MOD key on the right of the ENVELOPE page.
Pressing that will take you directly back to the MOD page:
This way, you can ‘toggle’ between the two pages quickly and easily to set mod amounts and
the source controller’s parameters.
At any time, to return to the mod matrix’s ROUTE page to select another route or add/delete a
routing, press EXIT or MOD.
Page 12

Alesis Fusion Specifications

General

Type	Workstation
Polyphony	64 voices
Synthesis Types	Sample Playback, Virtual Analog, FM, Physical Modeling
Display	240 x 128 pixel LCD
MIDI	In, Out, Thru
RAM	64MB (expandable to 192MB)
Weight (61-key)	28 lbs
Keyboard	61 or 88 keys
Keyboard Type	Semi-weighted (61-key), Hammer action (88-key)
Effects	Reverb, Chorus, Delay, Flanger, Phaser, Distortion, EQ
Storage	40GB internal hard drive
Sampling	Yes
Inputs	2 x 1/4" inputs, 1 x XLR
Outputs	4 x 1/4" outputs, 1 x Headphone
