10 IMCP0002 Rev.J
2.4 – Lifting
The handling of heat exchangers Compabloc should be done by using certified straps, slings and shackles, and also
by appropriate lifting means (jib or bridge crane).
• ertical Compabloc
Lifting rings and lugs are located on the top of the unit.
The nozzles must never be used for handling purposes.
Do not use the welded or screwed lifting lugs located on the panels for
lifting of the complete unit, these are for lifting individual panels only!
It is very important to check that the capacity of the lifting means correspond to the
lift weight.
In general, it is not recommended to handle the Compabloc by using a forklift truck.
For safety reasons, never stand or work under suspended loads.
