20
1 2 3
4
5
6 7
4
1 2
3
5
8
1
2
3
4
5
6
BH
1
2
3
4
0
1
2
4
3
5
0
1
2
3
4
5
6
1 Turn the handwheel toward you to raise the needle to
its highest position.
Raise the presser foot lifter.
2 Select the pattern "BH" by turning the pattern selector
dial.
If the BH pattern is already selected, reset the dial once
according to the procedure in 12 .
3 Attach the automatic buttonhole foot.
4 Pull the button holder to the back, and place the button
in it. Push back the button holder toward you as far as
it will go.
5 Pull the buttonhole lever downward as far as it will go.
Buttonhole lever
6 Insert fabric under the foot.
Turn the handwheel slowly towards you with your right
hand until the needle goes down and continue turning
handwheel until the take-up lever is at its highest position.
7 Remove the fabric to the left to draw both threads to
the left.
8 Insert the garment under the foot, and lower the needle
at the starting point.
Then lower the automatic buttonhole foot.
Note : Make sure there is no gap between the slider and the
spring holder. If there is a gap, the length of the rows
will be different, as shown.
Starting point
Slider
There should be no gap
Spring holder
Difference
Buttonhole
Pattern selector: (BH)
Presser foot: Automatic buttonhole foot
Thread tension: 1–5
Stitch length: (0.5 –1)
Stitch width: 5
4
1
2
3
5
* The size of buttonhole is automatically set by placing
the button in the automatic buttonhole foot.
* The button holder of the foot takes a button size up to
2.5 cm (1") in diameter.
* Make a test buttonhole on a sample duplicating the
fabric, interfacing and seams of the actual garment.
* Place the button on the fabric sample and mark the
top and bottom to determine the position of buttonhole.
* Use interfacing on stretch fabrics.
