Alfa Network A1930 - Disassembling of Operation Panel

13
WARNING
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start
of the sewing machine.
26. DISASSEMBLING OF OPERATION PANEL
Disassembling steps:
1. Use needle to open a. b. c. A. B.
2. Remove the operation panel, set aside.
Assembling steps:
Install the operation panel according to the first of disassembly after assembly.
