Interfaces
Interfaces: The Alfano 6 offers you to customize your racing
interfaces and thus create your display according to your
preferences or needs. You can also navigate through the racing
interfaces by pressing the button on the top right.
In order to customize your interfaces, go to the Course Display
Setup menu (icon at the top right corner of your main menu) where
you can create up to 4 screens.
Configuration:
1. Add a cell with the "+" icon
2. Move the cell on the screen
3. Choose the size of the cell
4. Change it's color (black or white)
5. Delete the cell
6. Name the interface
7. Pre-visualize the interface
8. Exit, Save or Delete the interface
Info: We indicate as "cell" a set of data displayed in connection with a sensor.
Example: The RPM sensor data is represented in the RPM cell
The light bulb icon allows you to configure the use of the LEDs for the interface you are designing.
10
