ALFRA ROTABEST 60 RL-E - Technical Data, Available Accessories

13
Technical Data
Prod.-no. and designation:
18626 ROTABEST 60 RL-E
Power consumption:
1800 Watt
On-load speed:
50-110 / 75-175 / 105-245 / 165-385
1
-min
Tool holder:
MT 3
Voltage:
(according to type plate)
230 V 50/60 Hz
110 V 50/60 Hz
Max. drilling Ø in steel
- Core drill:
- Twist drill:
80 mm
32 mm
3
1
8
⁄ “
1
1
4
⁄ “
Stroke:
190 mm
7 ½“
Cutting depth:
50 mm
2“
Tapping:
up to M30
Size of magnetic base:
92 x 238 mm
30° verstellbar rechts und links,
3
8
⁄ “ mm vor und zurück
3,62“ x 9.37“
30° adjustable left and right,
3
8
⁄ “ mm back and forth
Magnetic holding force:
20000 N
Weight:
22 kg
48,4 lbs
Noise emission:
92 dB(A) @ 300 mm distance
from the motor
92 dB(A) @ 12“ distance
from the motor
Vibration on the handle:
AC=3.5 mm/s² and VC=3.2 mm/s
Available accessories
 Transport Case
 Drill Chuck 3 -16 mm MT 3
 Coolant Unit
 Safety Belt
 Coolant Spray
 Allen Key 2,5 mm
 Chip Remover
 Allen Key 6,0 mm
