Synchronous Playback 16-ch @ 1080p, 4-ch @ 4K, 2-ch @ 12 MP
Video Output 2 × HDMI, VGA, CVBS
HDMI Video Output Formats HDMI1: 4K (3840 × 2160) / 60 Hz, 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080 / 60 Hz,
1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
HDMI2: 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
VGA Video Output Formats VGA1: 2K (2560 × 1440) / 60 Hz, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz”
Two Way Audio Input 1-ch, RCA (Linear, 1kΩ)
Audio Output 1-ch, RCA (Linear, 1kΩ)
Export Formats .MP4, .AVI
Ethernet 1 × Gbps RJ-45 self-adaptive Ethernet interface,
24 × 10 / 100 Mbps Self Adaptive PoE Ethernet interfaces
PoE interface IEEE 802.3af / at supported standard, 210 W max power output
USB 2 × USB 2.0 (front panel), 1 × USB 3.0 (rear panel)
Hard Drive Interface SATA
Hard Drive Capatcity 4x HDDs max., up to 10TB capacity per HDD
eSATA 1 × eSATA interface
Serial Interface 1 × RS-485, 1x RS232
Alarm Input 16
Alarm Output 4
Operating System Embedded Linux
Security Password Protection
Protocols IPv4, TCP / IP, UDP, HTTP, UPnP, RTSP / RTP / RTCP, SMTP, FTP, DHCP, NTP, DNS, ONVIF, HTTP multipart
Power Requirements 100 ~ 240 Vac
Max. Power ≤ 360 W
Power Consumption ≤ 20 W (without HDD or PoE enabled)
Weight 11 lb. (without HDD)
Dimensions (in.) 15.7 W” × 17.5” D × 2.8” H
Operating Temperature 14°F ~ 131°F
Color / Material Black
Material Aluminum
Approvals CE, FCC, RoHS, UL
Supplied Accessories Quickstart Guide
USB Mouse
110 Vac Power Cord
HDD sata cables
Rack Mount Ears
6ft HDMI Cable
6ft Ethernet Patch Cord
