Replacing the Front-Panel
Light Board
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Align the tabs on the front-panel light module with the slots on the front
panel, and snap the front-panel light module onto the front panel.
2 Route the front-panel light board cable through the cable-routing hole on
the chassis.
3 Connect the front-panel light board cable to the system board.
Post-requisites
1 Replace the video-card fan.
2 Replace the top cover.
3 Replace the base cover.
57
